    Aluminium Low Profile Spoke Type Load Cell For Scale 10 - 50 Kg

    Ask Lasest Price
    Brand Name : Ruijia
    Model Number : RJ-6621
    Price : USD 30/piece
    Payment Terms : T/T, L/C
    • Product Details
    • Company Profile

    Aluminium Low Profile Spoke Type Load Cell For Scale 10 - 50 Kg

    Product Description:

    The spoke load cell (also known as pancake load cell) is a small-sized, high-accuracy, tensile or compressive load cell with eccentric load capacity. It is widely used in electronics, tensile testing, shock testing, tank and silo level monitoring, and other industrial weighing systems.


    Features:

    • Product Name: Spoke Type Load Cell
    • Input Resistance: 750±30Ω
    • Protection Class: IP65
    • Compensated Temperature: -10℃~+60℃
    • Temperature Effect on Zero: ±0.05 %F.S./10℃
    • Insulation Resistance: ≥5000MΩ
    • Available as tension load cell and compression load cell
    • High accuracy Strain Gauge Load Cells

    Dimensions:


    Paremeters:


    CapacityKg10/20/50
    SensitivitymV/V1.5±0.2
    Accuracy%FS

    ≤±0.1

    Creep(15min)%FS≤±0.02
    Input ResistanceΩ370±30
    Output ResistanceΩ350±10
    Insulation ResistanceM Ω≥5000(100VDC)
    Zero Balance%FS≤±1
    Temperature Effects on Span%FS/10℃≤0.05
    Temperature Effect on Zero%FS/10℃≤0.05
    Rated Temperature Range-10~+60
    Operating Temperature Range-20~+80
    Proposed Excitation VoltageV6~12
    Allowed Excitation VoltageV18
    Safe Overload%FS120
    Ultimate Overload%FS150
    Protection IP65
    Cable specificationmmФ3
    Cable lengthm1
    Material Aluminum Alloy

    Packing and Shipping:

    FAQ:

    1. What detailed information do I need to provide if I want to place an order?
    We need to know the following information: Capacity, Usage and other related parameters you need.

    2.Do you accept customized?
    Yes, we have different customers make their own OEM products. So we can make products as per your requirement.

    3. When will you arrange the production?
    We will arrange the production immediately after receiving your payment.

    4. Can I get some samples before place order and how long for a sample?
    Yes, but customer needs to pay for the samples and freoght. The laed time for samples is about 7 days up on got payment.

    5. Do you have any discount?
    To clients who bring repeat orders and large orders. Please contact us for better quote.
    E-mail: frank0505@126.com yangzaiquan@xarj.cn Whats: +18992920670


    Looking forward to cooperating with you!
